Product Summary

The mrf619 is an NPN silicon RF power transistor. The MRF616 is Designed for Common Emitter Class C Amplifier Applications in 12.5 Volt UHF Mobile Radios.

Parametrics

mrf619 absolute maximum ratings: (1)IC: 250 mA; (2)VCBO: 36 V; (3)PDISS: 5.0 W @ TC = 25 OC; (4)TJ: -65 OC to +200 OC; (5)TSTG: -65 OC to +200 OC; (6)θJC: 35 OC/W.

Features

mrf619 features: (1)High Gain, 11 DB Typical; (2)Gold Metallization; (3)Emitter Ballasting.

Diagrams

mrf619 block diagram
