SN74LVC1G125DBVR

buffer gate, 100mA, 5.5V, SOT

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.10~0.13 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 2 :	0.13 / Piece
2 ~ 200 :	0.10 / Piece

PartNumber:: SN74LVC1G125DBVR

Brand:: Texas Instruments - TI | Pack: SOT | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. hellen's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-23

From Other Seller

Part Number:SN74LVC1G125DBVR
US $0.10 - 0.13
Quantity:

piece

Product Summary

The SN74LVC1G125DBVR is a single bus buffer gate with 3-state output. The SN74LVC1G125DBVR is designed for 1.65-Vto 5.5-VVCC operation. The SN74LVC1G125DBVR is fully specified for partial-power-down applications using Ioff.

Parametrics

SN74LVC1G125DBVR absolute maximum ratings: (1) Supply voltage range Vcc: -0.5 to 6.5V; (2) Input voltage range VI: -0.5 to 6.5V; (3) Voltage range applied to any output in the high-impedance or power-off state: -0.5 to 6.5V; (4) Voltage range applied to any output in the high or low state: -0.5 to Vcc +0.5V; (5) Input clamp current IIK: -50mA (VI<0) ; (6) Output clamp current: -50mA (VO<0) ; (7) Continuous output current Io: ±50mA; (8) Continuous current through VCC or GND: ±100mA; (9) Storage temperature range: -65 to 150°C.

Features

SN74LVC1G125DBVR features: (1) Available in the Texas InstrumentsNanoStar andNanoFree Package; (2) Supports5-V VCC Operation; (3) Inputs Accept Voltages to 5.5V; (4) Max tpd of 3.7ns at 3.3V; (5) Low Power Consumption,10-µA Max ICC; (6) ±24-mA Output Drive at 3.3V; (7) Ioff Supports Partial-Power-Down Mode; (8) Latch-Up Performance Exceeds100mA Per JESD78, ClassII; (9) ESD Protection Exceeds JESD22.
